Series MG-500
Impact Resistant Commercial Door

  • Meets Florida Building Code for High Velocity Hurricane Zone.
    Large missile rated
  • Sturdy 2-1/4” frame thick. 5” Medium Stile Commercial Door.
    Assembled via shear blocks and TIG welded for added strength
  • Single and Double door. Maximum dimensions with transom:
    87-1/2” x 144” (double) and 45-1/2” x 144” (single)
  • Max Pressure for single door +120/-130 PSF. For double door
    up to +/- 90 PSF
  • Glazing capabilities: 9/16” HS laminated and 1-1/8” insulated laminated
  • Options of high threshold (Water Rated) and ADA threshold
    (not water rated)
  • Can accommodate transoms and mates with storefront MG-5000
    without necessity of additional mullions
  • Push and Pull Handles. Concealed 3 point locks as well as panic devices
  • 4” x 4-3/4” Stainless steel all bearing hinges and offset pivots
  • Powder coating aluminum finish. Meets AAMA 2604 exigencies (5 year warranty) AAMA 2605 is also available (10 year warranty)
